Step 20 of 21

Step 20

Clip on the back flap

Photo: the back flap clipped onto the rear of the pelmet.
Photo: the back flap clipped onto the rear of the pelmet.
Video guideWatch the full walkthrough
  1. The back flap clips to the large pelmet at the back and faces the blind to create a light block.
  2. The plastic edge clips onto the matching lip on the back. Start at one end — it's firm, but you'll feel a definite clip.
  3. When it's on properly it sits at 90 degrees to the back section, nice and straight.
Recommended troubleshootingCommon questions for this step

If you hit a snag

Light bleeding from the top of the pelmet.

The back flap probably isn't clicked on fully. Re-seat it along the back lip and check it sits at 90 degrees.
